What are AN960 washers?
Christopher Pierce
Updated on May 01, 2026
Overview. AN960 flat washers are used under hex nuts to provide a smooth bearing surface, as shims to obtain the correct grip length for a bolt and nut assembly, and to adjust the position of AN310 and AN320 castle nuts with respect to drilled cotter pin holes in bolts and clevis pins.
What size is M22 washer?
Dimensions for DIN125 Form A Washers
| Bolt Size | Inside Diameter | Outside Diameter |
|---|---|---|
| M22 | 23mm | 39mm |
| M24 | 25mm | 44mm |
| M27 | 28mm | 50mm |
| M30 | 31mm | 56mm |
What material is an nas1149f0332p washer made of?
STEEL
We offer a quantity discounts based on the following table: Unit….NAS1149F0332P.
| Detail | Characteristic |
|---|---|
| MATERIAL | STEEL OVERALL |
| PERIPHERAL SHAPE STYLE | ROUND |
| SPECIAL FEATURES | LIGHT |
How are metal washers sizes?
Washers usually have an outer diameter (OD) about twice the width of their inner diameter (ID). High quality bolted joints require hardened steel washers to prevent the loss of pre-load due to Brinelling after the torque is applied.
How big is a #14 washer?
Flat Washer Dimensions
| Bolt Size | USS | SAE |
|---|---|---|
| 7/32 (#12) | – | 0.562 |
| 1/4 (#14) | 0.734 | 0.625 |
| 5/16 | 0.875 | 0.688 |
| 3/8 | 1.000 | 0.812 |
What is the width of most washing machines?
Standard Washer and Dryer Dimensions Front-loading and top-loading washing machines and dryers are about 27 inches wide by 35-43 inches high and 28-34 inches deep (without pedestals). Washing machines with a pedestal base are about 27 inches wide and anywhere from 47-55 inches high.
How much does an an960 flat steel wash cost?
AN960 FLAT STEEL WASHERS AN No. Superseding NAS No. Bolt / Screw Size O.D. (in.) Price AN960-3 NAS1149FN332P No. 3 0.250 $0.05 AN960-4 NAS1149FN432P No. 4 0.312 $0.02 AN960-5 NAS1149FN542P No. 5 0.438 $0.09 AN960-6 NAS1149FN632P No. 6 0.375 $0.03
What are Anan 960 flat washers used for?
AN960 flat washers are used under hex nuts to provide a smooth bearing surface, as shims to obtain the correct grip length for a bolt and nut assembly, and to adjust the position of AN310 and AN320 castle nuts with respect to drilled cotter pin holes in bolts and clevis pins.
What are the alternate part numbers for the an96010l?
Alternate Part Numbers SKU / Model: AN96010L Minimum Qty (MOQ): 100 NSN: 5310-00-167-0834 FSC: Nuts and Washers / 5310 Schedule B: 7318.22.0000
What is the bolt size on the an960-3 nas1149fn632p?
AN No. Superseding NAS No. Bolt / Screw Size O.D. (in.) I.D. (in.) AN960-3 NAS1149FN332P No. 3 0.250 0.105 AN960-4 NAS1149FN432P No. 4 0.312 0.125 AN960-5 NAS1149FN542P No. 5 0.438 0.14 AN960-6 NAS1149FN632P No. 6 0.375 0.149
